Camper Shell Compression Boot
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is extruded from durable EPDM synthetic rubber substance and has a flexible spring steel clip for fastening to any rim. This material is available by the foot. To find how much you require measure the distance encircling your cab opening. You get 3 alternatives of rubber to apply for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is straightforward and requires minimal tools. Just fit the seal tightly onto the rim of the window or pass through opening. This provides a tight connection between the two units. Regardless of whether you're hauling, this seal prevents rain and helps cabin integrity during your journey.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is developed to withstand challenging conditions such as UV exposure. It's tailored for both commercial fleets. Compared to standard seals, this material performs better. It's a smart investment for anyone looking to preserve their truck cab connection with a dependable sealing solution.
Camper Shell Compression Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Multi-Vehicle Fit | Works on trucks, vans, semi cabs, and custom enclosures | Versatile for commercial and recreational conversions |
| Audio Blow-Through Compatible | Perfect for stereo mods and custom subwoofer enclosures | Used in high-performance truck audio builds |
| Weather-Tested Seal | Handles rainstorms without leaks or performance loss | Reliable weather barrier for daily-use trucks or RVs |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Does the camper shell compression bootrequire glue to install?
No glue is required. The camper shell compression boot has a spring clip embedded in the EPDM rubber that clamps onto a thin flange. You can optionally glue the seam using cyanoacrylate (SuperGlue), but avoid petroleum-based adhesives.
- Will the camper shell compression boot work on a walk-through truck conversion?
Yes! This is a perfect use case. The camper shell compression boot allows you to join the truck cab and camper shell or utility box with a weather-sealed, flexible connection.
- Is it suitable for sealing between an airbag mounted truck cab and the body hard mounted to chassis rails on a truck?
As long as there is some sort of flange or wall to install the boot it should work. The thickness of the flange should not exceed 3/16" (4.7625mm) The accordion design allows for independent movement or flex between the cab bodies.
