Camper Shell Bottom Seal
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is extruded from robust EPDM synthetic rubber substance and uses a flexible spring steel clip for attaching to any rim. This material is available by the foot. To determine how much you require measure the length encircling your cab opening. You have 3 alternatives of rubber to employ for waterproofing your cabs together.
Tips for Getting the Right Fit
To specify how much you want measure the length around your cab opening. It is vital that both openings are accurately the same size. Make sure to measure the opening before ordering. Every installation is different.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is critical for your vehicle project. This rubber boot stands out due to its superior construction and customer-approved reliability. We take pride on providing products that surpass your demands for long-term durability. Don't settle for inferior seals, upgrade to one that's made for the road.
Camper Shell Bottom Seal Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Embedded Steel Spring Clip | Maintains a secure grip on flanges without adhesive | Stable connection between cab and shell |
| Weather-Tested Seal | Handles rainstorms without leaks or performance loss | Reliable weather barrier for daily-use trucks or RVs |
| EPDM Sponge Rubber Construction | Flexible, resilient seal that withstands weather and aging | Ideal for trucks, RVs, and sleeper cabs exposed to elements |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How much camper shell bottom sealdo I need?
This material is sold by the foot. To determine how much camper shell bottom seal you need, measure the full distance around your cab or window opening. Most full-size pickups need about 13–14 feet, while mini-trucks average around 10 feet.
- What type of rubber is used in your boots?
Our boots are made from high-quality black EPDM rubber, known for its durability, UV resistance, and flexibility across extreme temperatures.
- What do you charge for shipping?
Here are the various charges for shipping both Domestic and International
Part 540 Compression Boot - Flap $17.45 Part 541 Accordion Boot $17.45 Part 543 Wide Accordion Boot $24.35 Part 544 Extra Wide Accordion Boot $24.35 Part 545 Compression boot - Bulb $17.45 Canada $76.95 International $110.00
