Camper Shell Boot Seal
How to Choose the Right Rubber Boot Seal
You can acquire rubber boot material for your special project. This seal is extruded from resilient EPDM synthetic rubber substance and uses a pliable spring steel clip for affixing to any flange. This material is sold by the foot. To determine how much you require measure the distance encircling your cab opening. You have three options of rubber to employ for sealing your cabs together.
Tips for Getting the Right Fit
To ascertain how much you need measure the length around your cab opening. It is imperative that both openings are perfectly the equal size. Make sure to measure the opening before ordering. Every installation is different.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is commonly used in cab pass-through conversions. It's suitable for most light-duty trucks. Whether you're retrofitting a camper shell or building a personalized rig, this seal offers universal fitment and dependable performance for your cab connection project.
Camper Shell Boot Seal Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Weather-Tested Seal | Handles rainstorms without leaks or performance loss | Reliable weather barrier for daily-use trucks or RVs |
| EPDM Sponge Rubber Construction | Flexible, resilient seal that withstands weather and aging | Ideal for trucks, RVs, and sleeper cabs exposed to elements |
| Compressed and Expanded Flex | Adapts to body movement and misalignments | Maintains seal during travel, loading, or frame shifts |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I cut the camper shell boot seal to fit around a third brake light?
No, cutting is not recommended. Instead, remove the brake light and cover the hole, or change how the boot is mounted if you need to preserve the light.
- Can I order a sample of the camper shell boot seal?
Yes, you can order a sample pack that includes all boot types. It’s a great way to test fit and feel before committing to a full-length order.
- How do I know if I need a camper shell boot seal or a compression boot?
Use a camper shell boot sealwhen both openings are identical in size and shape. Use a compression boot if there are size differences or no solid flange available.
