Camper Compression Boot
How to Choose the Right Rubber Boot Seal
You can buy rubber boot material for your special project. This seal is manufactured from tough EPDM synthetic rubber substance and uses a pliable spring steel clip for attaching to any rim. This material is available by the foot. To specify how much you need measure the distance around your cab opening. You have several options of rubber to apply for sealing your cabs together.
Tips for Getting the Right Fit
To specify how much you require measure the length around your cab opening. It is vital that both openings are exactly the same size. Make sure to measure the opening before ordering. Every installation is different.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is designed to withstand harsh conditions such as heat. It's tailored for both long-term installations. Compared to cheaper seals, this material offers more protection. It's a solid choice for anyone looking to preserve their truck cab connection with a dependable sealing solution.
Camper Compression Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Urethane Adhesive Compatible | Allows permanent seal when needed for high-stress areas | Used in high-vibration or heavy-use applications |
| Cleanable Surface | Easy to wipe down or blow clean for reinstallation | Using mild soap and water for cleaning maintenance |
| Compressed and Expanded Flex | Adapts to body movement and misalignments | Maintains seal during travel, loading, or frame shifts |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How weatherproof is the camper compression boot?
The EPDM accordion boot creates an airtight, watertight seal when installed correctly. It's designed to keep rain, dust, and wind out — ideal for camper conversions and pass-throughs.
- Can I install a camper compression boot in cold weather?
Yes, but it's best to warm the camper compression boot slightly beforehand. Cold temperatures may make the rubber less flexible and harder to manipulate during installation.
- I have a Ford F150 with a LEER top. I an pretty sure the accordion seal is the correct option but the warning that the opening must be an exact match has me concerned. It looks like the truck opening is larger at the lower corners but until the window is removed, who knows? Am I on safe ground getting the accordion seal for this application?
The accordion boot only stretches one direction. There is a metal clip embedded in the rubber that allow you to attach the boot to the fiberglass/sheet metal, Therefore both window openings must be the same size. If the opening in the shell is smaller you can cut and trim the fiberglass to match the truck's window opening.
