Boot Between Truck Cab And Topper

Boot Between Truck Cab And Topper

How to Choose the Right Rubber Boot Seal

You can get rubber boot material for your special project. This seal is extruded from hard-wearing EPDM synthetic rubber compound and integrates a bendable spring steel clip for affixing to any rim. This material is sold by the foot. To find how much you require measure the distance around your cab opening. You have three options of rubber to use for sealing your cabs together.

Tips for Getting the Right Fit

To find how much you need measure the space around your cab opening. It is important that both openings are precisely the matching size. Make sure to measure the opening before ordering. Every installation is different.

Why EPDM Rubber Is the Best Choice for Long-Lasting Seals

The EPDM rubber seal is crafted to survive harsh conditions such as cold. It's ideal for both off-grid builds. Compared to standard seals, this material offers more protection. It's a solid choice for anyone looking to preserve their truck cab connection with a dependable sealing solution.

Boot Between Truck Cab And Topper Features and Benefits

Feature Benefit Use Case
Affordable, High-Value Solution Great quality at a competitive price point Cost-effective choice for budget-conscious builders
Trusted by Pros and DIYers Field-tested by thousands in real-world applications Confidence in product from verified reviews and installs
UV & Weather Resistant Withstands sun, rain, and temperature changes without cracking Long-term durability for vehicles stored outdoors

Order Form

To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.

Accordion Boot - Part Number 541

Accordion Boot

The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.

How Accordion Boot Works Animation

$8.95 per foot

In Stock

Order 541

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Compression Boot - Part Number 540

Compression Boot

Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.

How Compression Boot Works Animation

$7.95 per foot

In Stock

Order 540

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Extra Wide Accordion Boot - Part Number 543

Extra Wide Accordion Boot

The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.

$11.50 per foot

In Stock

Order 543

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Accordion Boot - Ultra Wide 10" Part Number 544

Accordion Boot 10 inch wide

The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.

$13.90 per foot

In Stock

Order 544

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Accordion Boot 15 - Part Number 546

Extra Wide Accordion Boot

The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.

$16.50 per foot

In Stock

Order 546

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Compression Bulb Seal - Part Number 545

Compression Bulb Seal

Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.

$8.25 per foot

In Stock

Order 545

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Frequently Asked Questions

  • Can the boot between truck cab and topper be painted?

    We only sell black boots, but EPDM rubber can be painted using an acrylic roof coating rated for EPDM. Avoid latex and petroleum-based paints.

  • Does the boot between truck cab and topper require glue to install?

    No glue is required. The boot between truck cab and topper has a spring clip embedded in the EPDM rubber that clamps onto a thin flange. You can optionally glue the seam using cyanoacrylate (SuperGlue), but avoid petroleum-based adhesives.

  • Can I custom trim a boot between truck cab and topper to fit my setup?

    You can trim the length to fit your application, but altering the shape, corners, or embedded clip area is not recommended.
