Auto Line Truck Boot
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is extruded from hard-wearing EPDM synthetic rubber substance and uses a flexible spring steel clip for attaching to any flange. This material is sold by the foot. To specify how much you need measure the length around your cab opening. You have several alternatives of rubber to apply for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is hassle-free and requires minimal tools. Just secure the seal tightly onto the lip of the window or pass through opening. This ensures a secure connection between the two units. Regardless of whether you're adventuring, this seal prevents rain and preserves interior comfort during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is important for your vehicle project. This rubber boot delivers due to its industrial-strength construction and customer-approved reliability. We focus on providing products that meet your expectations for long-term value. Don't settle for inferior seals, upgrade to one that's made for the road.
Auto Line Truck Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Cleanable Surface | Easy to wipe down or blow clean for reinstallation | Using mild soap and water for cleaning maintenance |
| Custom Length | Get the exact amount you need with no waste or shortages | Great for DIY box truck or custom overland builds |
| Silicone-Friendly Seam Sealing | Easy to seal end joints with a small bead of silicone | Ensures total waterproofing where ends come together |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I keep my sliding windows and still use a ?
Unfortunately, no. The slider windows must be removed because the auto line truck boot equires a clean flange or wall to attach. Sliders block access to this area.
- I`m about to put a a fiberglass shell on the back of my truck and I`m taking out the back window. I think the fiberglass shell opening is a bigger than the the back window of the truck. will the Accordion Boot or Compression Boot Gasket Material work?
In order for the accordion boot to work in your application both opening must be the exact size. If the opening in the fiberglass shell is smaller you have the option of resizing the opening to fit your rear window opening. If the opening in the fiberglass shell is bigger than the opening in your truck's window opening you are limited to using the compression boot.
- Is it suitable for sealing between an airbag mounted truck cab and the body hard mounted to chassis rails on a truck?
As long as there is some sort of flange or wall to install the boot it should work. The thickness of the flange should not exceed 3/16" (4.7625mm) The accordion design allows for independent movement or flex between the cab bodies.
