Accordion Window Seal
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is manufactured from resilient EPDM synthetic rubber compound and incorporates a bendable spring steel clip for affixing to any rim. This material is available by the foot. To determine how much you need measure the length around your cab opening. You get 3 options of rubber to employ for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is user-friendly and can be done with few tools. Just press the seal firmly onto the rim of the window or pass through opening. This creates a tight connection between the two units. Regardless of whether you're camping, this seal blocks moisture and helps temperature control during your journey.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is engineered to withstand extreme conditions such as sunlight. It's perfect for both long-term installations. Compared to standard seals, this material retains flexibility. It's a solid choice for anyone looking to upgrade their truck cab connection with a dependable sealing solution.
Accordion Window Seal Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Prevents Heat and Sound Transfer | Improves cab comfort by blocking wind and road noise | Useful for sleepers and audio builds |
| Supports Walk-Through Conversions | Lets you convert separate spaces into one continuous interior | Used in van builds, campers, and custom sleeper cabs |
| Compressed and Expanded Flex | Adapts to body movement and misalignments | Maintains seal during travel, loading, or frame shifts |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- What if the camper shell opening is larger than my truck window?
If the shell opening is larger, the accordion window seal may not work. You’ll either need to modify the opening or consider a compression boot instead, which is more forgiving in such situations.
- How weatherproof is the accordion window seal?
The EPDM accordion boot creates an airtight, watertight seal when installed correctly. It's designed to keep rain, dust, and wind out — ideal for camper conversions and pass-throughs.
- I am making a walk through conversion on my pickup truck to allow access in the bed. I want to to cut the wall between the cab and bed to make one continuous passenger cabin to the camper shell. I also want something that looks decent, and will last. Will the accordion boot work in this situation?
Yes, the accordion boot will work for you in this type of installation. For more details on how to create and seal a cut through go to the Cut Through FAQ page for more details
