Accordion Rubber Boot Seal
How to Choose the Right Rubber Boot Seal
You can buy rubber boot material for your special project. This seal is extruded from robust EPDM synthetic rubber substance and incorporates a flexible spring steel clip for affixing to any rim. This material is sold by the foot. To find how much you need measure the length around your cab opening. You have several alternatives of rubber to make use of for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is hassle-free and can be done with few tools. Just secure the seal tightly onto the rim of the window or pass through opening. This provides a secure connection between the two units. Whether you're hauling, this seal blocks rain and preserves a dry space during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is key for your vehicle project. This rubber boot stands out due to its superior construction and customer-approved reliability. We pride ourselves on providing products that surpass your expectations for long-term performance. Don't settle for flimsy seals, upgrade to one that's engineered for adventure.
Accordion Rubber Boot Seal Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Embedded Steel Spring Clip | Maintains a secure grip on flanges without adhesive | Stable connection between cab and shell |
| Cleanable Surface | Easy to wipe down or blow clean for reinstallation | Using mild soap and water for cleaning maintenance |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Do I need glue to install the accordion boot?
The rubber boot does not require glue for installation. It has a spring clip embedded in the rubber. When the boot is placed over a flange, the clip squeezes the rubber securely. The only optional gluing is at the seam using cyanoacrylate (SuperGlue). Avoid petroleum-based adhesives like rubber cement.
- I have a fiber glass camper shell. I want access to my camper shell from inside my cab but I don't want to lose heat and have a weatherproof seal. Will this product provide the right solution?
The accordion boot creates an air-tight and weather tight seal between the cabs. It does not provide any insulation. However, heat loss in minimize by the air-tight seal.
- Will one of these work on both sliding windows on truck & cap? I don't want to remove either sliding window.
In order for the boot to attach to the vehicle there must be some sort of thin wall or flange. Keeping the slider window will cover any flange or thin wall. In short you will not be able to use any or the boots if you keep the sliding windows in place as there will be no mechanical method to install the boot.
